The Run Down:
Spartan Turbocharger Systems (S.T.S.) have specially made these turbochargers to help Navara D40 & Pathfinder R51 owners with the YD25 engine!
To have a turbocharger that can make big HP and stay reliable at the same time is always the dream!
S.T.S. spec these units out with the best of the best parts!
They are designed to make up to 30PSI reliably, yet they also lower EGTs, EMP & drive better than your factory YD25 turbo!
Through vigorous testing they can comfortably say that these units make between 240HP/480NM. (Dependent on vehicle set up & tuner)
Features:
- Boost rating 16PSI - 30PSI
- 46mm 6+6 blade billet aluminium compressor wheel
- 9 Blade inconel hybrid turbine wheel
- Custom heavy duty bearing
- Oil & coolant cooled core
- Designed specifically for YD25 Engine with 4-bolt manifold flange
- Direct install, no modification required
- Pre-calibrated vacuum actuator
- Fits both Spanish & Thai models
Specs:
| Compressor |
Turbine |
Core |
| Inlet: 3 Inch | Inlet: Factory Flange | Lubrication: Oil |
| Outlet: Factory Size | Outlet: Factory flange | Coolant: Yes |
| Wheel: 46mm 6+6 Billet Aluminium | Wheel: 9 Blade Inconel Hybrid | Oil Fittings: Factory |
| Size: Factory AR.42 | Size: Factory AR.64 | Coolant Fittings: Factory |
Fitting Notes:
The 769708-STS is a 100% direct fit to your Nissan Navara D40 & Pathfinder R51 with the 4-bolt manifold flange.
You will require a 3 Inch exhaust system, upgraded intercooler, 30% larger injector nozzles & a custom ECU tune.
(Copy and paste tunes wont work on these turbochargers)
Brand: Spartan Turbocharger Systems (S.T.S.)
Model: 769708-STS
Part No: 769708-5004W / 769708-5004S / 769708-5004 / 769708-0004 / 769708-4 / 769708-5003S / 769708-5003 / 769708-0003 / 769708-3 / 769708-5002S / 769708-5002 / 769708-0002 / 769708-2 / 769708-5001S / 769708-5001 / 769708-0001 / 769708-1 / 767720-5004S / 767720-5004 / 767720-0004 / 767720-4 / 767720-5003S / 767720-5003 / 767720-0003 / 767720-3 / 767720-5002S / 767720-5002 / 767720-0002 / 767720-2 / 767720-5001S / 767720-5001 / 767720-0001 / 767720-1
OEM Part No: 14411EC00B / 14411-EC00B / 14411EC00C / 14411-EC00C / 14411EC00E / 14411-EC00E / JIC02166I / 14411-EB70A / 14411EB70A / 14411-EB70B / 14411EB70B / 14411-EB70C / 14411EB70C / 14411-EB70D / 14411EB70D / 14411-EB71A / 14411EB71A / 14411-EB71B / 14411EB71B / 14411-EB71C / 14411EB71C / 14411-EB71D / 14411EB71D
Vehicle: (Fits Thai & Spanish models)
- Nissan Navara D40 2.5L YD25 - 4-bolt flange
- Nissan Pathfinder R51 2.5L YD25 - 4-bolt flange
Cooling: Oil & Coolant
Gaskets: This turbo comes with a free complete gasket kit.
Warranty: 12 Months/25,000km - Whichever comes first
Delivery: Free post to Aus wide, normally takes 2-4 days to major cities.
